GE DS200DCFBG1BJB

DS200DCFBG1B provides control-level power to a dc drive or exciter and 115 V ac, typically used to power enclosure cooling fans.

• Manufacturer : GE

• Product No. : DS200DCFBG1BGB

• Product type : Power Supply Board

• DS = Identifies GE Industrial Control Systems

• 200 = Indicates that the board does not contain firmware. (215 indicates the board contains firmware and/or other components added to the base level board.)

• DCFB = Board functional acronym.

• G = A group, or variation, of a particular board.

• Weight : 1Kg

• Shipping weight : 1.5 Kg

The DCFB includes the following circuits:

Control-level power supplies (+5, ± 15, and ± 24 V dc) Motor or generator field power circuits (except the SCR module) Driver circuits for the armature SCR gate pulse generators DS200DCFBG1B got circuits to instrument numerous ac line and dc motor or generator signals, including: – Armature current and voltage – Field current – Ac line current – Ac line voltage magnitude and phase sequence To replace the DCFB board: 1. Turn off power to the equipment, then wait for a few minutes for the DS200DCFBG1B’s capacitors to discharge. Test any electrical circuits before touching them to ensure power is off. 2. Open the equipment cabinet door to access the printed wiring boards. This exposes the drive control card, which faces the front. DS200DCFBG1B mounted behind the drive control card, also facing the front. 3. Pull the locks located on either side of the cabinet. Lift the drive control card and tilt forward and down to expose the DS200DCFBG1B board. 4. To remove the DS200DCFBG1B board, carefully disconnect all cables as follows:    – For a ribbon cable, place one hand on each side of the cable connector that mates with the board connector. Gently pull the cable connector with both hands.    – For a cable with a pull tab, carefully pull the tab 5. Plastic snaps (holders) keeps the DS200DCFB in place. Push these holders back to release the board. 6. On the replacement board, set all jumpers and switches in the exact position as those on the board being replaced. If a board revision has added or eliminated a configurable component, or re-adjustment is needed 7. Install the new DS200DCFBG1B board, ensuring that all holders snap into position. 8. The cables labeled with the correct connector name, as marked on the DS200DCFBG1B board.    Reconnect all cables as labeled. Ensure the cable seating on both ends.
