PXI-4462 - NI | 188261H-11L Sound and Vibration Module

Description

National Instruments PXI-4462 4-Input Dynamic Signal Analyzer

Features: • 6 Gain Settings for Input Ranges from ±316 mV to ±42.4 V • 4 Simultaneously Sampled Analog Inputs ar up to 204.8 kS/S • Software-Configurable AC/DC Coupling and IEPE Conditioning • Variable Antialiasing Filters • Support for IEEE 1451.4 Class 1 Smart (TEDS) • 24-Bit Resolution ADCs with 118 dB Dynamic Range

The PXI-4462 (Part Number: 779688-01, 779131-01 ) PXI Sound and Vibration Module is a Dynamic Signal Acquisition or DSA device manufactured by National Instruments. The PXI-4462 is ideal for use in a wide variety of applications, such as environmental noise testing, rotating machinery evaluation, audio assessment, vibration analysis, machine condition monitoring, acoustic measurements, noise, vibration, and harshness measurements, and more. This Sound and Vibration Module has 24-bit resolution and a sample rate of 204.8 kS per second, the capability to sample and synchronize at the same time, and high-performing noise, distortion, and dynamic range. Several more of the useful features on the PXI-4462 include a four-channel dynamic signal acquisition and six gain settings to configure an input range. The device has a high-pass filter cutoff frequency of 3.4 Hz. On the PXI-4462 Sound and Vibration Module, the analog overload point for the 0 dB gain range is around 10.7 Vpk, which is the voltage when the front-end circuitry starts saturating. There is also a digital overload detection feature, which happens prior to the module fixing gain and offset errors. Since the PXI-4662 spots the overload prior to correcting the gain and offset errors, it will also catch an overflow setting in the ADC filter. The NI-DAQmx driver software is the primary software on which the PXI-4462 device is run, and should be installed (the driver software) before installing the device (the PXI-4462). The device is compatible with software packages/application development environments (ADEs) such as LabVIEW, LabWindows/CVI, Microsoft Visual C++, Microsoft Visual Basic, Borland C++, and Microsoft .NET. The device can be configured using the Measurement & Automation Explorer (MAX) tool.

                                                                                      PXI-4462

                                                                                      PXI-4462

                                                                                      PXI-4462

One year warranty, special discount after sale

The company focuses on DCS, PLC, robot, large servo four systems

The main products are all kinds of module/card, controller, touch screen, servo drive

The company's advantages: the supply of imported original products, professional production of accessories

Fast delivery time, complete supply, The seller has more than $1526000 worth of industrial control products inventory

We Can transport to the world！！！

① 24-hour email reply (12 hours);

② For shipment to countries outside Asia, please contact the seller.
