1398-DDM-075 | Allen Bradley Drives Servo
Description: The Allen-Bradley 1398-DDM-075 is an Ultra 200 Series Digital Servo Drive. This Servo drive is enabled when supplied with AC input voltage requirement of 100-240VAC rms, 1-phase or 3-Phase and input frequency of 47-63 Hz. This drive has peak output current of 50 Amperes for 1-phase input and 75 Amperes for 3-phase supply while the Continuous Output Current are 15 Amperes for 1-phase and 35 Amperes for 3-phase operation. The Peak Power Output is 14 kW for 1-phase and 20 kW for 3-Phase while the Continuous Power Output is 7.5 kW at 3-phase operation.
Technical Specifications for 1398-DDM-075
| Manufacturer | Rockwell Automation |
| Continuous Power Output | 3.5 A @120VAC; 7.5 A @ 3-phase |
| Weight | 21.32 lbs (9.67 kg) |
| Part Number/Catalog No. | 1398-DDM-075 |
| Brand | Allen-Bradley |
| Product Family | Ultra 300 Kinetix Servo Drive |
| Input Voltage | 100-240VAC, 1-phase; 100-240VAC, 1-phase; |
| Input Frequency | 47…63 Hz |
| Main AC input current, Nom (rms) | 1.0 A |
| Main AC input current, Nom (0-pk) | 0.5 A |
| Continuous output current (rms) | 50 A, 1-phase; 75 A, 3-phase |
| Peak output current (0-pk) | 15 A, 1-phase; 35 A, 3-phase |
| Bus Capacitance | 1170 Bus µF |
| Output Peak Current | 50 amps (Single Phase); 75 amps (Three Phase) |
| Bus Voltage | 141-339 Volts DC |
| AC Input Frequency | 47-63 Hz |
| Dimensions | 14.2 x 5.97 x 8.84 in (360.6 x 151.7 x 224.5 mm) |
| AC Input Current | 30 amps rms |
| Auxiliary Input-Voltage | 100-240V AC |
| Address Switch | 16-Position Rotary DIP |
| Peak Power Output | 240 Volts rms 14 kWatts (Single Phase) |
| AC Input Voltage | 100-240 Volts rms Nominal (Single or Three Phase) |
| AC Input Current | Torque or Velocity |
| Operating Temperature | 0 to 55 degrees Celsius |
| Product Line | ULTRA 200 Series |
| UPC | 662453565323 |
The Allen-Bradley 1398-DDM-075 is an Ultra 200 Servo Drive. This drive is one of the early Servo Drive products of Allen-Bradley. It is a microprocessor-based servo drive with built-in capabilities of managing drive current, velocity and position. The Ultra 200 Servo drive, such as the 1398-DDM-075 is compatible for use with brushless servo motors. In particular, the 1398-DDM-075 features an AC input voltage requirement of 100-240VAC rms, 1-phase or 3-Phase and input frequency of 47-63 Hz. It also has an auxiliary input which is supply voltage isolation to the main AC input circuit. The auxiliary AC input is rated 100-240VAC, 1-Phase with frequency of 47-63 Hz and current of 1.0 Amperes at 100VAC and 0.5 Amperes at 240VAC input. The drive’s bus voltage is 141-339 VDC with Bus Capacitance Energy Absorption of 152 Joules and bus capacitance of 4290 µF. It has a power dissipation 300 Watts. The 1398-DDM-075 module also features an analog output with a resolution of 8 bits and 12 bits. The analog input voltage ranges from 0-10 volts. The analog input uses 10-bit resolution. The 1398-DDM-075 has an integral supply and a shunt regulator, and it uses microcontrollers to manage a machine’s position, velocity, and current. The 1398-DDM-075 Servo Drive has great functionality and requires minimal maintenance. When maintenance is needed, the standard procedure is to check the whether the cable insulation and the connections are still good. The recommended moisture limit between 5 and 95%, the same as the other ULTRA 200 drives. The weight of the 1398-DDM-075 is 21.32 lbs. The peak output current for single-phase power and the peak output current for 3-phase power are 50A and 75A, respectively. The input frequency is 47-63 Hz. When operating the 1398-DDM-075 ULTRA 200 servo drive with single-phase power, the current limit must be set properly to avoid damage to the module.
