1756-L72S | Allen-Bradley | Automation Controller 8M/4M

Description

1756-L72S | Allen-Bradley | Automation Controller 8M/4M

Description: The 1756-L72S is part of the 5570 GuardLogix Programmable Automation Controller (PAC). This controller comes with standard and safety features and with embedded memory capacities of 4 Megabytes user memory, 2 Megabytes Safety memory, I/O memory of 0.98 Megabytes and 1 Gigabyte non-volatile memory which is provided by the 1784-SD1 that ships with the controller. It also comes with 1 USB communication port for local configuration of the controller. It is capable of handling up to 128,000 Discrete I/O and 4000 Analog I/O memory. This controller is Safety Integrity Level (SIL) 3 certified.

Technical Specifications for 1756-L72S

Manufacturer	Rockwell Automation
User Memory	4MB
Module Type	Processor Module
Series	GuardLogix 5570
Part Number/Catalog No.	1756-L73S
Brand	Allen-Bradley
Product Type	Programmable Automation Controller
Safety Partner controller	1756-L7SP
Safety Memory	2 MB
Non-volatile memory	1GB (ships with the controller)
Maximum I/O	128000
Maximum Analog I/O	4000
No. of standard task	31
No. of safety task	1
Programs per task	100 programs

Event Tasks	All triggers
Built-in communication	1 USB port
Energy Storage Modules	1756-ESMCAP c (Integrated); 1756-ESMNSE; 1756- ESMNRM
I-O Memory	0.98 MB
Maximum I-O	128,000
Maximum Analog I-O	4,000
Maximum Digital I-O	128,000
Current Draw (1.2 Volts DC)	5 Miliamperes
Current Draw (5.1 Volts DC)	800 Miliamperes
Power Dissipation	2.5 Watts
Thermal Dissipation	8.5 BTU per hour
Isolation Voltage	30 Volts Continuous
Enclosure	None (Open-Style)
UPC	10885630016471

The Allen-Bradley 1756-L72S is a GuardLogix 5570 controller that is a part of the Logix5000 family of controllers. It is a ControlLogix controller with safety control functions. It is a dual processor solution that must be used with a 1756-L7SP safety module to meet SIL 3 or Cat. 4/PLe safety standards. The safety partner controller is automatically configured, benefitting a single project. It has great processing capabilities and speed for motion and high-performance logic. It has a USB port for communication. It can support up to 500 controller connections. The 1756-L72S controller has 4MB of user memory, 2MB of Safety Memory, and 0.98MB of I/O memory. It can support 128,000 digital I/O and 4000 Analog I/O. It draws a current of 5mA at 1.2V DC and 800mA at 5.1V DC. It has a power dissipation of 2.5W and thermal dissipation of 8.5 BTU/hr. It weighs 0.55lbs and has an isolation voltage of 30V (continuous) for basic insulation. It can be installed in any slot of a ControlLogix 1756 Chassis and multiple controllers can also be installed in the same chassis. For safe communication, it uses ControlNet, DeviceNet, or EtherNet/IP networks. The 1756-L72S controller can control or monitor I/O over the backplane or through I/O links. For controller diagnostics, it has a front display that provides runtime information. It functions using energy storage modules, meaning that lithium batteries are not needed. A 1 GB (1784-SD1) Secure Digital card comes pre-installed as an optional non-volatile storage which can be expanded up to 2 GB (1784-SD2). The 1756-L72S may be installed to any standard or conformally-coated ControlLogix chassis such as 1756-A4, 1756-A4K, 1756-A7, 1756-A7K, 1756-A10, 1756-A10K, 1756-A13, 1756-A13K,1756-A17, and 1756-A17K, as well as standard power supplies such as 1756-PA50, 1756-PA72, 1756-PA72K, 1756-PA75, 1756-PA75K, 1756-PB50, 1756-PB72, 1756-PB72K, 1756-PB75, and 1756-PB75K.
