PCI-4065 | Digital multimeter equipment

Description

The National Instruments PCI-4065 (Part numbers: 779770-01, 190310C-01) is a Digital Multimeter Device with 6.5 Digits of Resolution. This device is used for the measurements of analog to digital and digital to analog voltage. This device can also measure analog to digital and digital to analog current, as well as perform diode tests. The NI PCI-4065 is preferable for educational laboratories and OEMs and can also be used for cost-conscious test and measurement applications. The NI PCI-4065 can measure 2 or 4-wire resistance. This DMM is structured with the voltage value of ±300. These values of voltage are measured in either DC or RMS. This DMM offers a comprehensive multimeter solution for basic 6.5 digit measurement requirements. The device has a maximum sample rate of 3 kS/s. It has a basic DC voltage accuracy of 90 ppm. The PCI-4065 should be calibrated a minimum of one time per year. However, the requirements for each user’s measurement application control how frequently the device should be calibrated. To calibrate the PCI-4065, the user needs a chassis, a multifunction calibrator, two insulated low thermal electromotive force spade lugs, two sets of low thermal electromotive force copper cables, a double banana plug with binding posts, and a way to create a short with low thermal EMF across the HI and LO input banana plug connectors on the PCI-4065. More information about calibrating the device can be found in the calibration procedure guide. The National Instruments PCI-4065 can measure the current range up to 3 A. The NI PCI-4065 driver is NI-DMM. National Instruments maintains the upgradation of the NI PCI-4065 DMM software, which helps prevent crashes and increases system and hardware performance. The user can obtain information with the Multimeter by using the NI-DMM instrument driver, DMM SFP, NI LabVIEW SignalExpress, or NI-DMM/Switch Express VI. The user can also run the NI-DMM examples to show the functionality of the PCI-4065. The PCI-4065 weighs 11.5 oz, and measures 7.2 x 0.8 x 4.7 in. in physical dimensions. It has recommended operating and storage temperature ranges of 0 to 40 °C and -40 °C to 70 °C respectively.

High dynamic range, dynamic signal acquisition module

PXI bus dynamic signal acquisition module, provides 8 analog signal synchronous input channels, ADC resolution 24bit, sample rate 204.8kSa/s, support AC/DC input coupling, each channel integrated independent IEPE excitation source. Connector type SMB.

peculiarity

◆ Sound, vibration test

◆ 24bit acquisition resolution, high dynamic range, high precision

◆ Adaptive anti-aliasing low-pass filter

◆ IEPE excitation source

Apply

◆ Dynamic structure test, sound/vibration test

◆ Speed meter sensor and microphone signal acquisition

◆ Audio amplifier and production instrument test

◆ Vibration table control, vibration analysis and machine condition monitoring

◆ Aerospace, aviation, shipping, nuclear power, automobile, research institutes

Coupling input, relay output, digital IO module

PXI bus 48 digital input and output module, providing 24 optocouplers isolated input channels, 24 solid-state relays isolated output channels, input channel level voltage high 80VDC, output channel switching level high 80VDC, switching current high 160mA, channels isolated from each other. Connector type SCSI-100 female connector.

peculiarity

◆ Isolation between channels

◆ 24 optocoupler input

◆ 24 solid state relay output

◆ Up to 80V input and output voltage range

◆ With programmable input filter, anti-shake

◆ Switching current 160mA

◆ Relay on-resistance: 1Ω

◆ Input change detection

◆ Programmable power-on status setting

Apply

◆ Automotive, aviation, industrial monitoring and control applications

◆ Aviation, laboratory research

◆ Biochemical automation test and measurement

The company focuses on DCS, PLC, robot, large servo four systems

The main products are various modules/cards, controllers, touch screens, servo drivers Company advantage: Supply imported original products, professional production of spare parts One year warranty, fast delivery time, complete supply !！！ ① 24 hours email response (12 hours); ② For shipment outside Asia, please contact the seller.
