ICS Triplex T9402 | Input module

Description

Description:The T9402 input module from Allen-Bradley is part of the AADvance Controllers series. It comes with 16 isolated input channels and it can be used as part of an AADvance system. The T9402 input module has an input voltage range of 0 to 32 Volts DC at 6.5 Amps.

Technical Specifications for T9402

Manufacturer：Allen-Bradley/Rockwell Automation

Series：AADvance Controllers

Part Number：T9402

Product Type：Digital Input Module

Number of Inputs：16

Input Isolation：Supported

Nominal Voltage：24 Volts DC

Backplane Voltage：18 to 32 Volts DC

Input Voltage：0 to 32 Volts DC

PLC Applications：Supported

The T9402 module is an input module from the Allen-Bradley/Rockwell Automation AADvance Controllers product line. It is a digital input module that has 16 input channels. Its nominal voltage rating is 24 Volts DC. The T9402 input module is a simplex dual or triple module that can handle 3 different scan times. These 3 different scan times are 0.924 milliseconds, 1.676 milliseconds, and 2.453 milliseconds. The T9402 digital input module can be used as part of a complete AADvance system, and it has been approved for safe operation in all non-hazardous environments and in hazardous environments with ratings of Class 1, Division 2, Groups A, B, C, and D (for North American industrial environments). This input module can be used in applications with programmable logic controllers or PLCs. The Allen-Bradley/Rockwell Automation T9402 digital input module from the AADvance Controllers series supports input electrical ratings that include an input voltage range of 0 to 32 Volts DC at a current rating of 6.5 Amps. Its backplane electrical ratings include a backplane voltage range of 18 to 32 Volts DC and a maximum backplane current rating of 260 milliamps. The maximum power consumption rating of the T9402 digital input module is 4 Watts and its maximum heat dissipation rating is 13.6 BTU per hour. This compact module only weighs 340 grams or 12 ounces. It is designed to be easy to install and configure and it does not require complex wiring or specialized tools to be installed or configured. All 16 of the input channels on the T9402 digital input module are isolated.

Data acquisition and monitoring control system 1. Supervisory Control And Data Acquisition (SCADA) system is a control system composed of computer equipment, industrial process control components and networks, and carries out data acquisition, monitoring and control of industrial production processes. To ensure the normal operation of the industrial production process, it is the nerve center of basic industries such as electricity, petroleum, metallurgy, natural gas, railway, water supply, chemical industry, which are related to the lifeblood of the country. 2, SCADA system is mainly used to control decentralized equipment. SCADA systems integrate data acquisition systems, data transmission systems, and HMI software to provide a centralized monitoring and control system for the input and output of many processes. The SCADA system collects field information, passes it to a central computer device, and displays it graphically or in text to the operator so that the operator can monitor or control the entire system from a real-time, central location. 3, SCADA system is the basis and core of industrial control network scheduling automation system. SCADA is responsible for collecting and processing all kinds of real-time and non-real-time data in the operation of industrial control system, and is the main data source of various application software of industrial control network scheduling center. SCADA system includes real-time data acquisition, data communication, SCADA system support platform, front subsystem, background subsystem and so on. 4, a SCADA system is usually composed of a master station and several sub-stations (remote terminal unit RTU or other automation system). The master station is usually in the dispatch control center (master station end), and the sub-station is installed in the factory station end. The master station communicates with the sub-station through the WAN to complete data acquisition and monitoring control. In addition to receiving the information of the sub-stations, the master station also receives the information forwarded from the subordinate dispatching control center master station by means of data communication, and forwards the information of the master station to the superior dispatching control center master station. The plant terminal is the real-time data source of SCADA system and the control destination. The data collected by SCADA includes analog measurement, state measurement point and pulse accumulation. The main station of SCADA system is divided into front subsystem and background subsystem, which are connected through LAN and communicate with each other. The front subsystem mainly completes the communication with the plant terminal and other dispatching control center, and sends the obtained data to the background subsystem, which carries out data processing.

TMR processor module Features: ◆ Based on the triplex processor system, all the important internal circuits are triplex fault-tolerant design; ◆ The main control chip adopts 64-bit 100MHZ Motorola RISC microprocessor (600 series); ◆ Small and light, the TRUSTED system is only 1/3 of the size and 1/14 of the weight of other TMR systems; ◆ Industry advanced industrial brain and bus system, system response time within 50ms (50 TMR points); ◆ Unlimited online modification; ◆ Complete I/O line monitoring function, support IO module online monitoring function, comprehensive monitoring of the status of the field signal; ◆ Availability of SIL3 safety system, up to 5 fault zones, fully compliant with TUV standard 3-2-0 degradation mode; ◆ The industry has module environment real-time monitoring function; ◆ The industry's safety instrument system as a whole SIL3 standard solution, the use of valve 7] test software to automatically monitor the change of valve stroke, diagnose the work of the safety stop valve, to improve the safety of the entire loop; ◆ ICS Triplex technology unique hardware voting (HIFT) technology; ◆ Automatic fault isolation without performance degradation; Support module hot replacement, trouble-free troubleshooting; ◆ Support for SIL 3 certified remote expansion rack fiber connection, greatly improve the flexibility of the system; ◆ Each analog point has an independent triplex AD converter, so there are actually 120 independent AD conversions inside a 40-point triplex analog module; ◆ Support all 5 IEC61131 programming languages: ladder logic diagram, function block, structured text, instruction table and control diagram.
