Bently Nevada 330105-02-12-90-02-05 | Reverse mounting probe

Description

Part Number: 330105-02-12-90-02-05 Manufacturer: Bently Nevada Product Type: 3300 XL 8 mm Reverse Mount Probes Storage Temperature : -51 °C to +177 °C (-60 °F to +351 °F) Total length option : 10 = 1.0 metre (3.3 feet) Availability: In Stock Country of Origin: United States(USA) 330105-02-12-90-02-05 is a 3300 XL 8 mm Reverse Mount Probe manufactured by Bently Nevada and used in Proximity Transducer System. The Proximity Transducer System and Sensors of the 3300 XL series work with replaceable probes of different lengths, armor, and connectors made by Bently Nevada.

330105-02-12-90-02-05 Functional Description The system generates an output voltage that is directly proportional to the distance between the probe tip and the observed conductive surface and can measure both static (position) and dynamic (vibration) values. The system's primary applications are vibration and position measurements on fluid-film bearing machines, as well as Keyphasor reference and speed measurements. The 3300 XL 8 mm system provides the most advanced performance in our eddy current proximity transducer systems. The standard 3300 XL 8 mm 5-metre system also fully complies with the API 670 Standard (4th Edition) for mechanical configuration, linear range, accuracy, and temperature stability. This level of performance is provided by all 3300 XL 8 mm proximity transducer systems, and complete interchangeability of probes, extension cables, and Proximitor sensors eliminates the need to match or bench calibrate individual components. Each component of the 3300 XL 8 mm Transducer System is backward and interchangeable4 with other non-XL 3300 series 5 mm and 8 mm transducer system components. This compatibility includes the 3300 5 mm probe, which is useful in applications where an 8 mm probe would be too large for the mounting space. Product Attributes Armored and Unarmored Options Multiple Connector Options Complete Interchangeability of Units and Cabling Configuration Cable Length: 0.5 m (1.6 ft) Connector: Miniature ClickLoc Coaxial Agency Approval: Required Total Length Option:0.5 metre (1.6 feet) Agency Approval: CSA, ATEX, IECEx Approvals

The eddy-current axis displacement sensor provides a simple and low-cost way to monitor the axis displacement of rotating machinery rotors directly with DCS and PLC interface. Real-time monitoring of shaft displacement of main engine and auxiliary equipment, such as steam turbine, compressor, fan, pump, motor, etc., can really protect such equipment. It is accurate in measurement, stable and reliable, and has strong anti-interference performance. ◆ Power supply: +24Vdc, maximum working current is less than 20mA. ◆ Input: HZ-891 series eddy current sensor probe. ◆ Spirit sensitivity: 8mA/mm. ◆ Accuracy: ≤1%. ◆ Transmission output: 4 ~ 20mA, maximum load resistance 500Ω. ◆ Output ripple: ≤20mV. ◆ Frequency response: 0 ~ 10KHz. ◆ Temperature bleaching: ≤0.1%℃. ◆ Overall size: 90mm(W)×35mm(L)×70mm(H). ◆ Installation size: base plate installation, 51mm×51mm, using four M4× 12GB29-76 bolts installation; Rail mounting, can be easily installed on the standard 35mm rail. ◆ Wiring mode: SpringLoc terminal is used, with automatic fastening function, and can be connected without installation tools, because it does not need bolts to be fixed, it will not loose. ◆ Operating temperature: -30℃ ~ 80℃.
