DSAI133A 3BSE018290R1 | ABB Analog Input Board

Description

General Information

• Product ID:3BSE018290R1

• ABB Type Designation:DSAI 133A

• Catalog Description:DSAI 133A Analog Input Board 32 Channels

• Long Description:Analog Input Board 32 Ch

  Note! This part is exempted from the scope of 2011/65/EU (RoHS)
  as provided in Article 2(4)(c), (e), (f) and (j) therein
  (ref.: 3BSE088609 – EU DECLARATION OF CONFORMITY
  - ABB Advant Master Process Control System)

Product Type:I-O_Module

Technical Information:Analog Input Board 32 Ch

HS Code:853890-- Parts suitable for use solely or principally with the apparatus of heading 85.35, 85.36 or 85.37.- Other

Product Net Depth / Length:324 mm

Product Net Height:22.5 mm

Product Net Width:225 mm

Product Net Weight:0.29 kg

RoHS Status:Not RoHs Compliant

WEEE Category:5. Small Equipment (No External Dimension More Than 50 cm)

Number of Batteries:0

SCIP:316d997c-2873-44db-b2fb-de0ac8719e42 Sweden (SE)

Analog input module is a device used to collect and process analog signals, which is usually composed of analog input circuit, analog-to-digital converter (ADC), filter and interface circuit. The analog input circuit is responsible for converting the external analog signal into a voltage or current signal, and then converting the analog signal into a digital signal through an analog-to-digital converter, and finally filtering and enhancing the signal through a filter, and finally output to a computer or other control equipment for processing and analysis. First, the type of analog module (1) Analog input module The analog input module, also known as A/D module, converts analog signals collected from various industrial field sensors into digital quantities that the CPU can recognize as received. (2) Analog output module The analog output module is also called the D/A module, which is simply to convert the digital quantity sent by the analog input module CPU into other external devices 1 to identify the received voltage or current and other information. (3) Digital module The main function of the digital module is to check the status of the external switch input. The digital input/output signal is a switching signal, 1 or 0. Second, the role of analog module 1. The main function of the analog input module is to collect analog signals. After collecting the external pressure sensor, the analog signal collected by the pressure sensor is collected inside the module and processed accordingly. Here the sensor data includes voltage, current, thermal resistance, thermocouple, temperature and other analog values, and then transmitted to the intelligent module of the computer through the bus. 2, the role of the analog output module is to convert the input digital signal through the digital-to-analog conversion, and the output can be controlled continuous current and signal. 3, digital module: digital module has two functions: input and output. If you do not use this method of integration, you can save more space, otherwise the user needs to buy two modules when using, the digital quantity module solves this problem, that is, integrate the input/output function, a module can both input signals and output signals.

Three, the five functions of the analog module 1. Collection function Collect pressure, temperature, displacement, other transmitter standard signals, as well as some flow meter, pulse meter flow data, equipment operating status and other data. 2. Control function Support automatic control, remote control of water pumps, valves and other control equipment. 3. Display function The display function is also digital tube display, LCD display is optional, and external display is also supported. 4, remote management function Support remote instrument setup and program upgrade via GPRS transmission device. The alarm function monitors the data, and reports the alarm information immediately if there is an abnormal situation. 5. Storage function The machine regularly saves the monitoring data, even if the power is cut off will not be lost. Fourth, the application field of analog input module Analog input modules have a wide range of applications in industrial automation, such as: 1. Industrial production process monitoring: The analog input module can be used to monitor and collect analog signals such as temperature, pressure and flow in the production process, and feed back to the computer or other control equipment in real time for monitoring and regulation of the production process. 2. Environmental monitoring system: The analog input module can be used for the collection and processing of parameters such as temperature, humidity and gas concentration in the environmental monitoring system, so as to grasp the changes and anomalies of the environment in time. 3. Power system monitoring: The analog input module can be used for the acquisition and monitoring of voltage, current, power and other parameters in the power system in order to understand the operating status and load of the power system in real time. 4. Instrument testing: Analog input module can be used for analog signal acquisition and processing in instrument testing in order to evaluate and verify the performance and accuracy of instruments.
