FM502-CMS 1SAP260400R0001 | ABB Function Module

Description

General Information

Extended Product Type:FM502-CMS

Product ID:1SAP260400R0001

ABB Type Designation:FM502-CMS

EAN:4016779830614

Catalog Description:Function module. 16 AI. 2 DI. 2 DC. 1 Encoder (FM502-CMS)

Long Description:FM502-CMS: AC500 Function module. 16 AI. 2 DI. 2 DC. 1 Encoder.

Dimensions

Product Net Weight:0.15 kg

Product Net Depth / Length:62 mm

Product Net Height:76 mm

Product Net Width:67.5 mm

Gross Weight:0.174 kg

Package Level 1 Depth / Length:84 mm

Package Level 1 Height:72 mm

Package Level 1 Width:71 mm

Package Level 1 Units:1 carton

Technical

Function:16 AI. 2 DI. 2 DC. 1 Encoder

Number of Digital Configurable I/Os:2

Degree of Protection:IP20

Supply Voltage:24 V DC
