330101-00-20-05-02-00 | Bently Nevada | 3300 XL 8 mm Proximity Probes

Description

The GE / Bently Nevada 3300 XL 8mm Proximity Probes are interchangeable probes of varying length, armor, and connectors that operates with the Proximity Transducer System and Sensors of the 3300 XL series.

Configuration: • Unthreaded Length: 0.0 in • Overall Case Length: 1.6 in • Total Length: 1.0 m (3.3 ft) • Connector and Cable-Type: Miniature Coaxial ClickLoc Connector, Standard Cable • Agency Approval: Multiple Approvals

Features: • Armored and Unarmored Options • Multiple Connector Options • Complete Interchangeability of Units and Cabling

• Manufacturer : Bently Nevada

• Product No. : 330102-00-20-05-02-00

• Product Type : 3300 XL 8 mm Proximity Probes

• Made in U.S.A

• 3/8-24 UNF thread, with armor

• Unthreaded Length Option : 00 = 0 in

• Overall Case Length Option : 20 = 2 in

• Total Length Option : 05 = 0.5 metre (1.6 feet)

• Connector and Cable-Type Option : 02 = Miniature coaxial ClickLoc connector, standard cable

• Agency Approval Option : 00 = Not required

• Weight : 0.323 Kg

• Shipping Weight : 1.5 Kg

The 3300 XL 8 mm Proximity Transducer System consists of: • One 3300 XL 8 mm probe, • One 3300 XL extension cable1, and • One 3300 XL Proximitor* Sensor2. The system provides an output voltage that is directly proportional to thedistance between the probe tip and the observed conductive surface and canmeasure both static (position) and dynamic (vibration) values. The system’sprimary applications are vibration and position measurements on fluid-filmbearing machines, as well as Keyphasor* reference and speed measurements The 3300 XL 8 mm system delivers the most advanced performance in our eddycurrent proximity transducer systems. The standard 3300 XL 8 mm 5-metresystem also fully complies with the American Petroleum Institute’s (API) 670Standard (4th Edition) for mechanical configuration, linear range, accuracy, andtemperature stability. All 3300 XL 8 mm proximity transducer systems providethis level of performance and support complete interchangeability of probes,extension cables, and Proximitor sensors, eliminating the need to match orbench calibrate individual components.

Each 3300 XL 8 mm Transducer System component is backward-compatible andinterchangeable4 with other non-XL 3300 series 5 mm and 8 mm transducersystem components5. This compatibility includes the 3300 5 mm probe, forapplications in which an 8 mm probe is too large for the available mountingspace Proximitor Sensor The 3300 XL Proximitor Sensor incorporates numerous improvements overprevious designs. Its physical packaging allows you to use it in high-density DINrail installations. You can also mount the sensor in a traditional panel mountconfiguration, where it shares an identical 4-hole mounting “footprint” with olderProximitor Sensor designs. The mounting base for either option provideselectrical isolation and eliminates the need for separate isolator plates. The 3300XL Proximitor Sensor is highly immune to radio frequency interference, allowingyou to install it in fiberglass housings without adverse effects from nearby radiofrequency signals. The 3300 XL Proximitor Sensor’s improved RFI/EMI immunitysatisfies European CE mark approvals without requiring special shielded conduitor metallic housings, resulting in lower installation costs and complexity. The 3300 XL’s SpringLoc terminal strips require no special installation tools andfacilitate faster, more robust field wiring connections by eliminating screw-typeclamping mechanisms that can loosen.
