Description
The Bently Nevada 3500/65 Temperature Monitor provides 16 channels of temperature monitoring and accepts both resistance temperature detector (RTD) and isolated tip thermocouple (TC) temperature inputs. The monitor conditions these inputs and compares them against user-programmable alarm setpoints. The monitor is programmed using the 3500 Rack Configuration Software. You can configure the 16-Channel Temperature Monitor to accept isolated tip thermocouples, 3-wire RTD, 4-wire RTD, or a combination of TC and RTD inputs.
Features• Accepts from 1 to 16 signals• Input impedance: Greater than 1 MΩ• Power consumption: 3 watts• Front panel LEDs: OK, TX/RX, Bypass• Type E, J, K, T thermocouples• 100 Ω 3-wire and 4-wire platinum RTD
The 3500/65 monitor provides 16 channels of temperaturemonitoring and accepts both resistance temperaturedetector (RTD) and isolated tip thermocouple (TC)temperature inputs. The monitor conditions these inputs andcompares them against user-programmable alarmsetpoints. The monitor is programmed using the 3500 RackConfiguration Software. You can configure the 16-ChannelTemperature Monitor to accept isolated tip thermocouples,3-wire RTD, 4-wire RTD, or a combination of TC and RTD inputs. In Triple Modular Redundant (TMR) configurations, you mustinstall temperature monitors in groups of 3 adjacentmonitors. In this configuration the monitor uses 2 types ofvoting to ensure accurate operation and to avoid singlepoint failures.
Manufacturer : Bently Nevada
Product No. : 145988-02
Product Type : 3500/65 Temperature Monitor
Made in U.S.A
16 Channel Temperature Monitor Module
Shipping weight : 2 Kg
TDI provides common functionality to the entire framework, but is not part of the critical monitoring channel and does not affect the correct and regular operation of the overall monitoring system. Each framework requires one TDI or RIM. The TDI occupies only one slot in the frame and must be located in the first slot (next to the power module).
For triple module redundancy (TMR) applications, the 3500 system requires TDI in the form of TMR. In addition to all the features of the standard TDI, the TMR TDI also has a "Monitor channel comparison function". The 3500TMR configuration performs the monitoring voting function by selecting the installation function of the monitor option. In this way, TMR TDI continuously compares the outputs of three redundant monitors. If TMR TDI detects that the output of one monitor is not equal to that of the other two monitors (within a percentage of the configuration), it issues an error indication to the monitor and adds an event to the system event list. The 3500 system is used to continuously monitor rotating and reciprocating machinery used in a variety of industries, especially in automatic shutdown machine protection applications that require extremely high reliability and availability. The types of machines that can use the Bentley 3500 system include, but are not limited to: Gas turbines, steam turbines, compressors, turbo expanders, electric motors and generators, exciters, gearboxes, pumps, fans, fans, reciprocating compressors, extruders and ball making machines. The available Bentley (bently3500 Series) monitor module channel types are as follows: Radial vibration, axial (lateral) displacement, differential expansion, speed, acceleration, shell expansion, valve position, standard tachometer, overspeed tachometer, shaft vibration, standard single slope differential expansion, double slope differential expansion, zero speed tachometer, etc.
