PXI-8106 -NI Embedded Controller

Description

Featured with an Intel Core 2 Duo processor T7400 (2.16 GHz dual-core), Mobile Intel 945GM Express chipset, and Intel GMA 950 graphics media accelerator, the National Instruments PXI-8106 (Part Numbers: 779886-01, 779886-00, 779887-00, 779887-01) is an Embedded Controller for PXI systems. This Controller has all standard and extended PC I/O ports in one unit. With several I/O ports available on the PXI-8106, almost all active slots on the chassis remain available for control and measurement modules. The device is equipped with a maximum system/slot bandwidth of 132 Mb per second, and a 4 Mb L2 cache. This one-piece rugged Controller helps minimize integration related issues and eliminates the requirement for complicated cabling to daughter boards. The NI PXI-8106 Embedded Controller comes equipped with four Hi-Speed USB ports (for connecting a mouse or a keyboard), one CD-ROM/DVD-ROM drive (for OS or other software installation), and one IEEE 1284 ECP/EPP (to connect to a broad range of devices such as printers, scanners, and tape backup drives). In addition, the PXI-8106 Controller has an RS232 port available for coupling to serial devices. This Embedded Controller comes equipped with an integrated GPIB (IEEE 488) controller for the controlling of external instrumentation. The NI PXI-8106 operates using the NI-DAQmx driver hardware in conjunction with application development environments such as LabWindows/CVI, LabVIEW, and Measurement Studio. The device is also compatible with the NI-VISA software which is an API used for communicating and controlling instruments such as Serial, PXI, USB, GPIB among many others. For optimal video performance, the NI PXI-8106 features an Intel GMA 950 graphics media accelerator- a unique arrangement that provides optimized memory resources usage between the system and the graphics for smooth performance. Additionally, there is a DVI-I video connector provided, which is compatible with analog VGA and digital DVI. Users with analog monitors can utilize the DVI-I to VGA adapter, which can be purchased separately as an accessory. The instrument has a weight of 2.1 lbs., and the dimensions: 3.2 x 5.1 x 8.5 in.

High dynamic range, dynamic signal acquisition module PXI bus dynamic signal acquisition module, provides 8 analog signal synchronous input channels, ADC resolution 24bit, sample rate 204.8kSA /s, support AC/DC input coupling, each channel integrated independent IEPE excitation source. The interface type is SMB. peculiarity ◆ Sound and vibration test ◆24bit acquisition resolution, high dynamic range, high precision ◆ Adaptive anti-aliasing low-pass filter ◆IEPE excitation source Application program ◆ Dynamic structure test, sound/vibration test ◆ Speed sensor and microphone signal acquisition ◆ Audio amplifier and production instrument test ◆ Vibration table control, vibration analysis and machine condition monitoring ◆ Aerospace, aviation, shipping, nuclear power, automobile, research institutes

Flexible configuration, voltage, current analog output module PXI bus 32 analog signal output module, providing 32 analog signal output channels, DAC resolution 16 bits, refresh rate 40kS/s, each channel can be independently configured with voltage output or current output, while 8 auxiliary digital signal input and output, 2 32-bit multi-function counter. Connector Type DB-62 Female connector. peculiarity ◆ Flexible configuration, voltage output or current output ◆ Multiple output ranges are available ◆ Support static output and dynamic output ◆ Up to 32 synchronous outputs ◆ Programmable power-on output state ◆ Multi-function auxiliary IO (AuxIO) ◆ A variety of triggering methods Application program ◆ Simulation and control ◆ Automatic test and measurement ◆ Scientific research, design verification, manufacturing testing ◆ Aerospace, aviation, shipping, nuclear power, automobile, research institutes

The company focuses on DCS, PLC, robot, large servo four systems

The main products are various modules/cards, controllers, touch screens, servo drivers Company advantage: Supply imported original products, professional production of spare parts One year warranty, fast delivery time, complete supply !！！ ① 24 hours email response (12 hours); ② For shipment outside Asia, please contact the seller.
