PXI-6514 - NI Digital I/O Module

Description

The NI PXI-6514 (Part Number: 778965-01) is an industrial, 64-Channel, ±30 VDC, isolated PXI Digital I/O Module. This module has 32 source/sink input lines and 32 source output lines. To ensure safer operation when connected to industrial process actuators, the user can configure the initial output state through software. The inputs and outputs in the individual banks of the NI PXI 6514 remain isolated from the inputs and outputs in all the other banks. This module is suitable for general-purpose data acquisition applications, automated manufacturing test, and industrial control. This PXI Digital I/O Module can sense DC signals from 11 to 30 V. While applying a DC voltage of a minimum 11 V across two input terminals, the PXI 6514 registers a logic high for that input. If a voltage of 4 V or less is present across the two input terminals, the device registers a logic low for that input. This model is entirely software configurable; thus, it is not required to set jumpers for any I/O configuration. Additionally, the PXI-6514 has programmable power-up states, which provide safe functioning when linked to relays, pumps, motors, and valves. The National Instruments NI PXI-6514 features a digital filtering function. This function can be used for the elimination of noise and spikes on the input data. This model also incorporates NI digital I/O watchdog technology that provides protection against a broad range of fault conditions, such as application crash, computer crash, driver crash, etc. With its change detection function, the user can automatically trigger their software application to proceed with a digital read operation upon a change of state. The PXI-6514 is run using the NIDAQmx driver software which is compatible application development packages like LabVIEW or LabWindows/CVI. The NI PXI-6514 Digital I/O Module has a 100-pin high-density SCSI connector, which can be linked to 100-pin ribbon cables or shielded cables. This module can be utilized with the R1005050 ribbon cable and two CB-50 or CB-50LP Connector Blocks for unshielded connectivity or with the SH100-100-F Shielded Digital I/O Cable and the CB-37FH DIN-rail-mountable Connector Block for shielded connectivity.

Analog input module is a device used to collect and process analog signals, which is usually composed of analog input circuit, analog-to-digital converter (ADC), filter and interface circuit. The analog input circuit is responsible for converting the external analog signal into a voltage or current signal, and then converting the analog signal into a digital signal through an analog-to-digital converter, and finally filtering and enhancing the signal through a filter, and finally output to a computer or other control equipment for processing and analysis. Working principle 1. Analog input circuit: The analog input circuit is a key part of the analog input module, which is mainly responsible for converting the external analog signal into a voltage or current signal. Common analog input circuits include resistance divider circuit, current voltage circuit and so on. The resistance divider circuit realizes the signal conversion through the series parallel combination of resistors, and the current voltage circuit realizes the signal conversion through the product of current and resistance. 2. Analog-to-digital converter (ADC) : The analog-to-digital converter is the core component in the analog input module, which is responsible for converting analog signals to digital signals. The analog-to-digital converter discretizes the input voltage or current into a series of digital values according to its magnitude, and converts the continuous analog signal into a discrete digital signal through a process of sampling and quantization. Common analog-to-digital converters include successive approximation analog-to-digital converters and integral analog-to-digital converters. 3. Filter: The filter is an important part of the analog input module, which is mainly used to filter and enhance the signal. The filter can improve the quality and stability of the signal by removing high-frequency noise and interference signals, thus improving the accuracy and reliability of subsequent processing. 4. Interface circuit: The interface circuit is the connection bridge between the analog input module and the computer or other control equipment, which is responsible for converting the digital signal into a form that the computer or other control equipment can recognize and process. Interface circuit usually adopts serial communication interface or parallel communication interface, and realizes data exchange and communication with computer or other control equipment through data line and control line.

Application field Analog input modules have a wide range of applications in industrial automation, such as: 1. Industrial production process monitoring: The analog input module can be used to monitor and collect analog signals such as temperature, pressure and flow in the production process, and feed back to the computer or other control equipment in real time for monitoring and regulation of the production process. 2. Environmental monitoring system: The analog input module can be used for the collection and processing of parameters such as temperature, humidity and gas concentration in the environmental monitoring system, so as to grasp the changes and anomalies of the environment in time. 3. Power system monitoring: The analog input module can be used for the acquisition and monitoring of voltage, current, power and other parameters in the power system in order to understand the operating status and load of the power system in real time. 4. Instrument testing: Analog input module can be used for analog signal acquisition and processing in instrument testing in order to evaluate and verify the performance and accuracy of instruments.
