Description
Configuration: • 33MHz MC68040RC33A Processor with Floating-Point Coprocessor • Second-Generation Petra ASIC Chip • 512 KB of SRAM on Main Board • 1 MB of Flash Memory • (4) IndustryPack Ports • SCSI/Ethernet Interface • Serial Port B Interface: EIA-232-D (DCE) Serial Interface Module, Model Number: SIMM06 Features: • Double-High VME Module • MC68LC040 or MC68040 Microprocessor • 1MB, 4MB, or 8MB of Parity-Protected DRAM • 512KB SRAM The Emerson / Motorola MVME162 is a double-high VME module equipped with an MC68LC040 or optional MC68040 microprocessor. (The MC68040 microprocessor has a floating-point coprocessor; the MC68LC040 does not.) The MVME162 has 1MB, 4MB, or 8MB of parity-protected DRAM; 512KB SRAM (with battery backup); a TOD clock (with battery backup); an optional LAN Ethernet transceiver interface with DMA, two serial ports (EIA-232-D and EIA-232-D/EIA-530); six tick timers with watchdog timer(s); optional SCSI bus interface with DMA; VMEbus interface (local bus to VMEbus/VMEbus to local bus, with A16/A24/A32, D8/D16/D32 bus widths and a VMEbus system controller).
Four-slot IndustryPack logic interface for embedded monitoring and controlapplications The MVME162P4 family provides OEMs and solutions developers an ideal platform forembedded monitoring and control applications. It allows an OEM to minimizeengineering expenses while integrating value-added hardware and softwareapplications onto an off-the-shelf product. In order to provide this wide range of solutions, the MVME162P4 allows a variety ofMPU, memory and interface options such as floating point, Ethernet, SCSI and VME.The result is a variation of the MVME162P4, which most closely fits the applicationrequirement. The inclusion of the new “Petra” application-specific integrated circuit (ASIC), whichreplaces functions formerly implemented in the IP2 chip, MC2 chip and MCECC chip,improves the performance of the memory subsystem. Memory configuration switchesenable the customer to tailor memory size for applications requiring smaller memoryconfigurations.
■ Choice of processors: 32 MHz MC68040 enhanced32-bit microprocessor with 8KB of cache, and MMUand FPU; or 25 MHz MC68LC040 enhanced 32-bitmicroprocessor with 8KB of cache and MMU ■ A32/D64 VMEbus master/slave interface withsystem controller function ■ High-performance DMA support for VMEbus D64 andlocal bus memory burst cycles ■ 16MB of configurable SDRAM ■ 512KB SRAM with battery backup ■ 1MB Flash memory for on-board monitor/debugger oruser-installed firmware ■ 8K x 8 NVRAM and time-of-day clock with batterybackup ■ Two serial communication ports, console port asEIA-232-D DCE and second port user configurable forEIA-232-D/EIA-422 (V.36) DTE/DCE ■ Four 16- or two 32-bit IndustryPack® ports with oneDMA channel per port ■ Optional SCSI and Ethernet interfaces ■ Six 32-bit timers, one watchdog timer
