Description
PLC features and functions (1) The main characteristics of plc. The characteristics of plc are: reliable work, fast running speed, building block structure, flexible combination, good compatibility, simple programming and generation, rich, strong network function. (2) The main functions of plc. plc system can well complete the industrial real-time sequence control, condition control, counting control, step control and other functions; It can complete analog/digital (a/d), digital/analog (d/a) conversion, data processing, communication networking, real-time monitoring and other functions. Years of practice shows that plc, reliable, is designed for the factory, with reinforced components according to the requirements of the working environment, real-time scanning practice and fault diagnosis function, easy troubleshooting, won the preference of users. What makes a plc so reliable is a real-time core or operating system of executable relay logic, sequential function diagrams, function blocks, structured text, command catalogs, or a combination thereof. In case of failure, the built-in device can maintain mechanical damage and maintain an orderly and predictable sequence. 2.4 The development trend of plc: there are extremely fast logical operations and logic control, sequence control capabilities, reliability in discrete control, convenient and easy to learn programming methods, so that it has an undisputed position in the field of industrial automation based on discrete.
The servo driver, also known as the servo amplifier or amplifier, is a device that outputs the pulse signal or analog signal input from the controller to the motor after internal calculation and amplification. Structure and principle The servo driver is composed of servo control unit, power drive unit and communication interface unit. The servo control unit includes position controller, speed controller, torque controller and current controller. The servo driver can be divided into two modules, the power board and the control board, which are relatively independent in function. The power board is the strong current part, which includes two units, one is the power drive unit IPM used to drive the motor, and the other is the switching power supply unit to provide digital and analog power for the entire system. The control board is the weak current part, the control core of the motor and the operating carrier of the core control algorithm of servo drive technology. The control board outputs PWM/PFM signal through the corresponding algorithm, which is used as the drive signal of the drive circuit to change the output power of the inverter, so as to achieve the purpose of controlling the AC servo motor.
Servo motor, according to the requirements of the control command, the power is amplified, transformed and regulated, so that the torque, speed and position control of the output of the drive device is very flexible and convenient. Because of its "servo" performance, it is named as a servo motor. Its function is to convert the input voltage control signal into the angular displacement and angular velocity output on the axis drive control object. Servo motors are generally divided into two categories: DC servo motors and AC servo motors. Ac servo motor The rotor inside the AC servo motor is a permanent magnet, and the U/V/W three-phase electricity controlled by the driver forms an electromagnetic field, and the rotor rotates under the action of this magnetic field, while the encoder of the motor comes with a feedback signal to the driver, and the driver adjusts the rotor rotation Angle according to the feedback value and the target value. When the AC servo motor has no control voltage, only the pulsating magnetic field generated by the excitation winding is in the stator, and the rotor is stationary. When there is a control voltage, a rotating magnetic field is generated in the stator, the rotor rotates in the direction of the rotating magnetic field, in the case of constant load, the speed of the motor changes with the size of the control voltage, when the phase of the control voltage is opposite, the servo motor will reverse. Dc servo motor The working principle of DC servo motor is basically the same as that of ordinary DC motor. Electromagnetic torque is generated by the action of armature air flow and air gap flux to make the servo motor rotate. The armature control method is usually used to change the speed by changing the voltage while keeping the excitation voltage unchanged. The smaller the voltage, the lower the speed. When the voltage is zero, stop rotating. Because when the voltage is zero, the current is also zero, so the motor will not produce electromagnetic torque, neither will there be rotation phenomenon. Dc servo motor is widely used in numerical control system, but DC servo motor also has some disadvantages: its brush and commutator are easy to wear; The maximum speed limit of the motor, the application environment limit; The structure is complicated, the manufacture is difficult and the cost is high.
The company focuses on DCS, PLC, robot, large servo four systems
The main products are various modules/cards, controllers, touch screens, servo drivers Company advantage: Supply imported original products, professional production of spare parts One year warranty, fast delivery time, complete supply !！！ ① 24 hours email response (12 hours); ② For shipment outside Asia, please contact the seller.
