Description
Description: The Allen-Bradley/Rockwell Automation 2711P-T12C6D1 terminal is a DC-powered operator interface terminal. It is part of the Panelview Plus 1250 series and it can be used to control and to monitor different applications. The 2711P-T12C6D1 operator interface terminal�s input voltage rating is 18 to 32 Volts DC. Additionally, its operating temperature range is from 0 to 55 degrees Celsius and its storage temperature range is from -25 to 70 degrees Celsius. The 2711P-T12C6D1 operator interface terminal is controlled by a 12.1-inch touchscreen with color graphics.
Technical Specifications for 2711P-T12C6D1
| Manufacturer | Rockwell Automation |
| Brand | Allen-Bradley |
| Part Number/Catalog No. | 2711P-T12C6D1 |
| Product Line | Panelview Plus 1250 |
| Display Size | 12.1 inches |
| Input Type | Touchscreen |
| Display Type | Full Color |
| Communication | DH+/RIO/DH-485 |
| Input Power | 18-32 Volts DC |
| Memory | 64 Megabytes |
| Shipping Dimensions | 11.12 x 14.3 x 2.17 inches |
| Product Lifecycle Status* | Discontinued/Obsolete |
The 2711P-T12C6D1 PanelView Plus 1250 is a product of Allen-Bradley/Rockwell Automation with a touchscreen of 12.1 inches that doubles as a vivid color display. The 2711P-T12C6D1 has a DH+/DH- 485 Communication DC Power Logic Module and a memory space of 64MB. For additional functionality, terminals may be ordered with extra options and extended features. The Legacy PanelView Plus and PanelView Plus 6, series 700 to 1500, are compatible with the 2711P-T12C6D1, although they do not have communication modules installed that support DeviceNet communication or remote I/O. For the logic modules used with the 2711P-T12C6D1 PanelView Plus as well as the PanelView Plus CE terminals, the catalog numbers 2711P-RPA, 2711P-RP, 2711P-RPD, 2711P-RP2x, 2711P-RP1x, 2711P-RP6x, 2711P-RP7x, and 2711P-RP3x, and the PanelView Plus 6 terminals are all incompatible. The Operator Interface of the 2711P-T12C6D1 PanelView Plus Operator Interface supports a smooth input through a keypad that comes with 40 keys, along with a touchscreen for additional input measures. These modules use both RS-232 and Ethernet through the module’s multiple built-in communication ports. In addition, this module also has two USB ports. The 2711P-T12C6D1 displays, controls, and monitors information. This unit features a variety of communication methods, memory for storage, labeling, and display size options. It is suitable for use because it decreases maintenance as well as costs through common components compatible with different applications.
