Description
Description: The Allen-Bradley/Rockwell Automation 2094-BM05-M servo drive is an Allen-Bradley Kinetix 6200 series multi-axis servo drive. It is part of the Allen-Bradley Kinetix 6200 series 400 Volts voltage class with a 3-phase input voltage rating of 460 Volts. The 2094-BM05-M multi-axis servo drive comes with a built-in safe speed monitor device. Its ambient operating temperature range is 0 to 50 degrees Celsius or 32 to 122 degrees Fahrenheit. The 2094-BM05-M multi-axis servo drive can be mounted inside a cabinet.
Technical Specifications for 2094-BM05-M
| Manufacturer | Rockwell Automation |
| Brand | Allen-Bradley |
| Weight | 12.0 lbs (5.44 kg) |
| Dimensions | 5.5 x 11.9 x 14.7 in (141 x 302 x 426 mm) |
| Operating Temperature | 32-122 F (0-50 C) |
| Output Current | 45 Amperes |
| Power Module | Axis Module |
| Max Bus Capacitance | N/A |
| Wattage | 22 kWatts |
| Voltage Rating | 460 Volt (AC) |
| Nom Drive Voltage | 360-480 Volts (3 Phase) |
| Part Number/Catalog No. | 2094-BM05-M |
The Allen-Bradley 2094-BM05-M is a Kinetix 6200 modular multi-axis servo drive. It is an Axis Module with 460V AC three-phase input power. It contains a 45A inverter section and requires one control module with an IAM power module. It has dimensions of 5.5 x 11.9 x 14.7 inches and weighs 12 lbs. The 2094-BM05-M drive is designed to provide Integrated Motion capability for motor or drive applications. It can easily transition from Safe Torque Off to Safe Speed Monitor and from SERCOS interface to EtherNet/IP networks. It is compatible with the Kinetix 6000 servo drive allowing easy migration whenever needed. The drive’s embedded safety removes the need for additional panel space or for wiring from an external safety monitor. The Safe Speed Monitor functionality allows maintenance work without stopping the machine. The 2094-BM05-M drive’s modular design and embedded safety features provide easy maintenance and flexibility. It also simplifies wiring, reduces spare parts inventory, and it can be modified with advancing technology. It reduces downtime and energy and production waste and improves operating efficiency with the Safe Speed feature. Its embedded advanced safety features also help protect personnel. Other safety features include Safe Maximum Speed, Safe Maximum Acceleration Monitoring, Safe Direction Monitoring, Zero Speed Monitoring, Enabling Switch Control, and Door Monitoring and Control. The 2094-BM05-M has enhanced diagnostic features which tell the nature of a fault by displaying error messages.
