Description
Description: The VPL-B1003F-PJ14AA low-inertia servo motor is an Allen-Bradley/Rockwell Automation VPL series 400 Volts low-inertia servo motor. It is able to operate reliably at low inertia levels because of its powerful permanent magnet stacks. The VPL-B1003F-PJ14AA low-inertia servo motor’s standard features include its shaft key and its absolute multi-turn digital feedback encoder. It also has a built-in holding brake that can hold its shaft at 0 RPM in applications where the motor needs to achieve a specific torque rating before the shaft starts spinning. The shaft in the VPL-B1003F-PJ14AA low-inertia servo motor can spin at up to 4500 RPM.
Technical Specifications for VPL-B1003F-PJ14AA
| Manufacturer | Rockwell Automation |
| Brand | Allen-Bradley |
| Part Number/Catalog No. | VPL-B1003F-PJ14AA |
| Product Type | Low-inertia Servo Motor |
| Voltage | 400V |
| Frame Size | 100 mm |
| Rated Speed | 4500 rpm |
| Magnet Stacks | 3 |
| Feedback | 18-bit absolute multi-turn digital encoder (Hiperface DSL protocol) |
| Shaft | Shaft Key |
| Connector | Single SpeedTec DIN connector, right angle, 325° rotatable |
| Mounting Flange | IEC metric, free mounting holes (type FF) |
| Factory Options | Standard |
| Brake | 24V DC |
The VPL-B1003F-PJ14AA servo motor is manufactured by Allen Bradley. Servo motors are devices that help in the precision controlling of angular/linear position, acceleration, and velocity. It comes with a 480 Volts AC voltage supply. It comes in different frame sizes and it can offer torque ranges from 0.54 N-m to 14.78 N-m. It is a low-inertia device with three magnet stacks and it comes with an F winding. It has a factory-rated 4500 RPM speed. The VPL-B1003F-PJ14AA comes in a 100-millimeter Bolt circle frame and it has stainless steel shafts and fasteners. It has single-turn and multi-turn encoder feedback which are high in resolution and consists of 18 bits and 24 bits of resolution, respectively. The VPL-B1003F-PJ14AA has a keyless shaft enclosure and it can be rotated to a maximum of 325 degrees. A 24 Volts DC holding brake is present to control the device. A SpeedTec DIN connector also comes with it. This device has a single cable used for feedback purposes, motor braking, and also for the motor power. The VPL-B1003F-PJ14AA comes with many different features to aid in the controlling of velocity and acceleration. It displays the real-time performance of the motor and passes this information to the control panel via the feedback devices. This information comes in handy as different adjustments and configurations can be made based on this real-time information. It comes certified with various standards like the CE, C-Tick, UL, and CSA. The VPL-B1003F-PJ14AA is being widely used in various sectors. It is used in printing, automated machinery, packaging, and also in the food and beverage industry.
