2711P-RP2 - Logic Module

Description

Description: The Allen-Bradley/Rockwell Automation 2711P-RP2 logic module is a DC-powered logic module. It is designed to be mounted on the back of a display module from the Allen-Bradley Panelview Plus 700, 1000, 1250, or 1500 series. The 2711P-RP2 logic module and the display module together make a Panelview terminal that can control industrial machines and systems. This logic module is equipped with 128 MB of flash memory and 128 MB of RAM. The 2711P-RP2 logic module is also equipped with an Ethernet port.

Technical Specifications for 2711P-RP2

The PanelView Plus operator terminal component with part number 2711P-RP2 is a logic module that has a built-in internal memory of 128 MB Flash Memory and 128 MB Random Access Memory. This logic module is compatible for installation to PanelView Plus 700-1500 operator terminals. The 2711P-RP2 is attached to the display module. It hosts a variety of communication interfaces as well as the supply voltage terminal. Specifically, it has One (1) Ethernet Communication Port, One (1) Serial communication terminal and Two (2) USB ports. It is powered by an external 24VDC Power supply with a Power Dissipation of 70W. A PanelView Plus and PanelView Plus CE operator terminal is supplied by Allen-Bradley with a display module and logic module as a minimum. These components create a fully functional hardware. With this, the 2711P-RP2 is a replacement part to the existing unit. It may be a direct replacement or an upgrade. Additionally, the internal memories such as Random Access Memory (RAM) and Flash memory may be upgraded. The built-in upgradable memory of the 2711P-RP2 is 128 MB Ram and 128 MB Flash memory. The logic module is attached to a specific slot of the operator terminal. It may only be used with PanelView Plus CE 700, 1000, 1250, 1500 operator terminals. This logic module has electronic components within that is sensitive to electrostatic discharge and requires careful handling during unpacking and installation. Also, the Allen-Bradley 2711P-RP2 Logic Module is conformally-coated with available options for the 700-1500 PanelView Plus Terminals. The standard features that come with the 2711P-RP2 logic module are ActiveX controls, third-party device support, a PDF reader, and an FTP server connection. This unit comes with the 2711P-RW2 Compact Flash and the 2711P-RR128 RAM. This unit comes equipped with an Ethernet port, two USB ports, one RS-232 port, and a CompactFlash card slot. This unit is available Series A, Series B, Series C, Series D, Series E, Series F, and Series G. The 2711P-RP2 Ser G is the latest series and one of the most common series of this logic module.
