IC200PWR102B - Power Supply Module

Description

Description: The IC200PWR102 is a Power supply module that is part of the VersaMax product family, currently under Emerson Automation, formerly produced by GE Intelligent Platforms. This power supply module is a 120 / 240 VAC expanded power supply with input supply voltage of 85-132 VAC / 176 - 264 VAC, 47-63 Hz. It has an output voltage of 5 VDC and 3.3 VDC and total output current of 1.5 A, maximum specifically, 1.0 A, maximum at 3.3 VDC and 1.5 A, maximum at 5 VDC output.

Technical Specifications for IC200PWR102

Brand	GE Fanuc
Series	Versamax
Product Description	Power Supply module
Manufacturer	GE Fanuc (Former); Emerson Automation (Current)
Input Voltage, range	85-132 VAC; 176 - 264 VAC
Part Number	IC200PWR102
Series	VersaMax
Input frequency	47-63 Hz
Input Voltage	120/240 Volts AC
Product type	Expanded Power Supply
Output Voltage	5 Volts DC and 3.3 Volts DC
Output Voltage	5 VDC; 3.3 VDC
Input voltage range	85 to 132 VAC (with jumper); 176-264 VAC (without jumper)
Extended Power	Yes
Total output current	1.5 Amperes
input voltage, nominal	120 VAC; 240 VAC
Input frequency	47-63 Hz
Output current at 3.3 VDC	1.0 A, maximum

Input Power	27 VA
Output current at 5VDC	1.5 A, maximum
Holdup Time	20 ms
Built-in module protection	Short circuit; Overload
Holdup time	20 ms
Total Output Current	1.5 Amperes Maximum
Output voltage	5.5 VD; 3.3 VDC
Protection	Short circuit, overload
Input voltage selection	Jumper installed: 120 VAC Jumper uninstalled: 240 VAC
Output current, Total	1.5 A, maximum
Dimensions	49 mm (1.93 in) x 133.4 mm (5.25 in) x 39 mm (1.54 in), not including the height of the carrier or the DIN-rail
Output current, 3.3 VDC	1.5 A, maximum
Output current, 5VDC	1.0, maximum

The IC200PWR102 is an expanded power supply module that is part of the VersaMax product family. This module is currently manufactured by Emerson Automation, formerly by GE Intelligent Platforms (GE IP). It is mainly used to deliver power to VersaMax backplane which is utilized by the installed modules to power up individual internal circuitries for operation. The IC200PWR102 is operable when connected to an external power supply that delivers 85-132 VAC (120 VAC, nominal) and 176 - 264 VAC (240 VAC, nominal), input frequency range of 47-63 Hz, and input power of 27 VA. This power supply delivers an output voltage 5 VDC and 3.3 VDC and output current of 1.0 Ampere at 3.3 VDC and 1.5 Amperes at 5 VDC however, the output current of the module shall not exceed the total maximum output current of 1.5 Amperes. The IC200PWR102 input voltage selection is configured by installation of a jumper across the two (2) terminal located on the right side of the ground terminal. With a jumper installed, the module accepts 120 VAC nominal voltage otherwise, without a jumper installed, the module is rated 240 VAC, nominal.

The IC200PWR102 is a power supply module that used with VersaMax input and output modules, Network Interface Units (NIUs)m Intelligent Modules and Central Processing Units (CPUs). This module may also be used with as a supplemental power supply module when installed on a Power Supply Booster carrier. For module protection, this hardware comes with an internally installed short circuit and overload protection. The GE Fanuc Versamax IC200PWR102 expanded power supply unit supplies power to devices that are connected to the backplane of PLC such as network interface units (NIUs), input and output units (I/O), and central processing units (CPUs). It uses AC power as the main power source unlike other types of modules from the Versamax series that use DC power. Although it serves as the primary power supply in the PLC, it can also be used as a secondary power supply when connected to a power supply booster carrier. The IC200PWR102 expanded power supply unit has an input voltage of 120 to 240 Volts AC and an output voltage of 5 Volts DC and 3.3 Volts DC. The module has an extended power feature, which means that the power can be expanded up to 3.3 Volts DC. It has an input power of 27 Volts-Amps and a holdup time of approximately 20 milliseconds. The GE Fanuc Versamax IC200PWR102 expanded power supply module is safeguarded against short circuits and overloading. This module has a frequency range between 47 Hertz and 63 Hertz. If a jumper is present in the module, the input voltage may range between 85 and 132 Volts AC, although 120 Volts AC is the nominal voltage rating. If the jumper is absent, the input voltage may range between 176 and 264 Volts AC, and the nominal voltage is 240 Volts AC. The jumper operates safely with an input voltage of 120 Volts AC. However, it is recommended not to use a jumper with a 240 Volts AC input voltage rating because it may damage the IC200PWR102 module and it may be fatal to the users.
