Features: • 1-Slot, C-size, Register Based • Armature Latching Relay Channels • Numerous Multiplexer Topologies • Configurable for Scanning Voltmeter Applications The Agilent / HP E1460A High-Density Relay Multiplexer is a C-size, 1-slot, register-based VXI module. This 64-channel multiplexer, using latching armature switches, offers a highly configurable, high point-count switching topology. Switching topologies include 64 two-wire, 32 three-wire, 32 four-wire, or 128 single- ended latching relay channels. Use of SCPI commands or status bit jumpers on the terminal card configures the E1460A "wire mode" as either a 128 x 1-wire, 64 x 2-wire, 32 x 3-wire, or 32 x 4-wire multiplexer. Applications for the E1460A include wire harness and cable testing, semiconductor testing, and printed circuit board testing. The E1460A shares the same switch card with the E1468A and E1469A; each product's unique terminal block determines the matrix configuration. Therefore, you can change matrix topology simply by plugging in the various terminal blocks. The terminal blocks can be obtained separately. All the E1460/68/69A matrix modules offer similar densities, with different row/column sizes and identical performance specifications.
The Agilent E1460A High-Density Relay Multiplexer is aC-size, 1-slot, register-based VXI module. This64-channel multiplexer, using latching armature switches,offers a highly configurable, high point-count switchingtopology. Switching topologies include 64 two-wire, 32 threewire, 32 four-wire, or 128 single-ended latching relay channels.This multiplexer consists of a component card with switches(labeled E1460-66202) and the QUIC screw terminal block(E1460-80011) that plugs onto the component card. Use of SCPI commands or status bit jumpers on the terminalcard configures the E1460A “wire mode” as either a 128x1-wire, 64x2-wire, 32x3-wire, or 32x4-wire multiplexer. Applications for the E1460A include wire harness and cabletesting, semiconductor testing, and printed circuit boardtesting.
The switch consists of eight banks of eight Hi and Loswitches, each bank having its own eight Hi and Lo common.There are seven programmable control switches and six setsof wire jumpers. These wire jumpers allow all bank commonsto produce either eight 1x8 two-wire multiplexers, four 1x8two-wire multiplexers, and two 1x16 two-wire multiplexers, orfour 1x16 two-wire multiplexers. Other switching topologiesare also possible. One 2.5-in analog bus cable (E1400-61605) is included toconnect the analog buses of multiple slot-adjacent E1460Amodules or a slot-adjacent E1411B multimeter module. Theanalog bus cable, easily installed at the faceplate of thecomponent card, lets you connect the E1460A with the E1411BDMM. Using SCPI commands sent to the E1411B, you canclose channels configured as two-wire, three-wire, orfour-wire in the E1460A. It is possible (but less convenient) toconnect the analog bus by attaching your own wiring to theE1460A and E1411B screw terminals.
