Description
Tricon Onsite cable connection The optional external terminal board is used to connect to the equipment in the field. Alternatively, you can connect your cable directly to the 56-pin connector on the top of the Tricon backplane. For more information about terminal boards, see the Terminal Board User's Manual. Programming workstation The Tricon system is programmed through an engineering and maintenance workstation called Tristation. Tristation1131's development platform runs on the WINDOWS operating system. Tristation 1131 supports three IEC 1131-3 compliant programming languages: Functional Block language, ladder Diagram language, and Structured Text Language. Tristation 1131 is used for the following purposes: - Develop and debug the control program that Tricon executes. - Diagnose the system status. - Mandatory point during loop detection and on-site device maintenance. Once a control program has been developed, the load operation installs the program into the controller and verifies that it performs correctly.
1.2.5 Environment Specifications
Tricon Because of the large number of components that make up a system, these specifications are not necessarily universal for every component.
Table 1-2 General environment specifications of the Tricon system Room temperature refers to the temperature measured at the bottom of the rack.
1.3 Working Principle
The triple module redundancy (TMR) structure ensures the device's fault tolerance and provides intact, uninterrupted control in the event of hardware failures in the component or transient failures from internal or external sources.
Each I/O module contains three independent sub-circuits. Each circuit on the input module reads process data and transmits this information to its corresponding main processor. The three main processors communicate via a dedicated high-speed bus system called TriBus.
Fiber-Optic RemoteExtender Modules (RXM) For operation of Expansion Chassis upto 7.5 miles (12 kilometers) away fromthe Main Chassis, with exceptionalimmunity against electro-static andelectro-magnetic interference. Interface Modules • HART Analog Input InterfaceModules act as an interface between4-20 mA analog input points fromHART smart devices in the field andHART Host software running on aPC. • HART Analog Output InterfaceModules act as an interface between4-20 mA analog output points fromHART smart devices in the field andHART Host software running on aPC. I/O Modules • Digital Input Modules receivediscrete signals of these nominalvoltages: 115 VAC/VDC, 48VAC/VDC, and 24 VAC/VDC. Allvoltages are available in TMRmodules. Non-TMR modules areavailable in 24 VDC and 48 VDConly. Speed input and totalizationmodules are also available. • Supervised Digital Output Modulesproduce discrete output signals ofthese nominal voltages, withdiagnostic coverage of the fieldcircuit and load device: 115 VAC,120 VDC, 48 VDC, and 24 VDC. • Digital Output Modules producediscrete output signals of thesenominal voltages: 115 VAC, 12018Product SpecificationsVDC, 24 VDC, and 48 VDC. Dualoutput modules are also available. • Analog Input Modules receiveanalog signals of these types: 0-5VDC, -5 to +5 VDC, 0-10 VDC, andThermocouple types J, K, T and E.Available in both isolated and DCcoupled versions. • Analog Output Modules areavailable in these versions: eightoutput points at 4-20 mA; six outputpoints at 4-20 mA and two at 20-320mA; and four output points at -60 to60 mA.
