CC-TAON11 - Analog Output Module

Description

The CC-TAON11 (51306521-175) analog output module features eight channels, each capable of delivering a 4-20mA signal to control valves, actuators, and other field devices.  The module supports both voltage and current output, providing flexibility in system integration.  The module also includes advanced diagnostic features, including open, short, and over-range detection, to ensure reliable operation and easy maintenance. Product Parameters Number of channels: 8 Output range: 4-20mA Output type: Voltage or current Output resolution: 16 bits Output accuracy: ±0.1% of span Update rate: 10ms per channel Power consumption: 1.5W per channel Specifications Operating temperature: -40°C to 70°C (-40°F to 158°F) Storage temperature: -40°C to 85°C (-40°F to 185°F) Operating humidity: 5% to 95% RH, non-condensing Storage humidity: 5% to 95% RH, non-condensing Power supply: 24VDC nominal, ±10% Dimensions: 11.8cm x 12.7cm x 2.5cm (4.65in x 5in x 0.98in) Weight: 0.2kg (0.44lb)

Features All Series C components feature an innovative design that supports enhanced heat management. This unique lookprovides a significant reduction in overall size for the equivalent function. The unique features of Series C I/O include: • I/O Module and field terminations are combined in the same area. The I/O Module is pluggedinto the IOTA to eliminate the need for a separate chassis to hold the electronics assemblies. • Two level “detachable” terminals for landing the field wiring in the enclosure, providing easierplant installation and maintenance. • Field power is supplied through the IOTA, with no need for extra power supplies and theassociated craft wired marshalling. • Redundancy is available directly on the IOTA without any external cabling or redundancy controldevices, by simply adding a second IOM to an IOTA. • The Series C innovative styling is one of its unique features. This styling includes features tofacilitate the effective use of control hardware in a systems environment. These features include: • Vertical mounting for more effective wiring since most field wiring applications require entry from the top or bottom ofthe systems cabinet. • An “information circle” for a quick visual cue to draw the Maintenance Technician’s eye to important statusinformation. • “Tilted” design for effective heat management within the cabinet enclosure. Since Series C allows for a significantincrease in cabinet density, an effective heat management system is critical for high systems availability. • Input and output circuits are protected from shorts to alleviate the need for in-line fusing, reducing installation andmaintenance costs. Series C IOTAs combine multiple functions into a single piece of equipment: • Single and redundant configurations. • On-board termination of process signals. • On-board signal conditioning. • On-board connection to appropriate networks (FTE, I/O LINK). • Field power distribution without external marshalling. • IOM plugs into the IOTA and receives power from the IOTA. • The IOTA receives its power from a 24 VDC bus that is part of the IOTA carrier – the IOTA is screwed into thebussed power

I/O Module Functions • High Level Analog Input /HART Input Module (16pt) – The High Level Analog Input Module supports both highlevel analog and HART inputs. Analog inputs are typically 4-20mA DC for both traditional and HART devices. HARTdata can be used for status and configuration. HART data, such as the secondary and tertiary variables, can also beused as process control variables. Two versions are available. • High Level Analog Input w/o HART (16pt) - The High Level Analog Input Module supports high level analog inputsAnalog inputs are typically 4-20mA DC for traditional devices. • Analog Output/HART Output Module (16pt) – The Analog Output Module supports both standard 4-20mA DCoutputs and HART transmitter outputs. Two versions are available. • Analog Output w/o HART (16pt) – The Analog Output Module supports standard 4-20mA DC outputs. • Digital Input 24 VDC (32pt) – Digital input sensing for 24V signals. Two versions are available. • Digital Input High Voltage (32pt) – Digital input sensing for 110 VAC, 220 VAC, 125VDC. • Digital Output 24 VDC (32 pt) – Current sourcing digital outputs. Outputs are electronically short-circuit protected.Two versions are available. • Relay Digital Output (32 pt) – Digital output with NO or NC dry contacts. Can be used for low power or high powerapplications. • Temperature Multiplexer (64 pt) – Provides thermocouple (TC) and resistance temperature device (RTD) inputs.The Multiplexer supports up to four, field proven PMIO FTAs. • Temperature Multiplexer (64 pt) – Provides thermocouple (TC) and resistance temperature device (RTD) inputs.The Multiplexer supports up to four, field proven PMIO FTAs • Pulse Input (8pt) – Provide linear counting, PV generation, and Quaduature Input for Custody Transfer • Universal Input Output (32 pt) - Supports 32 channels of user configurable IO. Choices available – analog input,analog output, digital input, and digital output.
