Description
Description: The Spectrum Controls 1769SC-IF4IH is a 1769 CompactLogix and MicroLogix 1500 compatible analog input module with Four (4) 0-20 mA, 4-20 mA plus HART and 0-5 V, 1-5 V, 0-10 V, ±10 V input signals. This module has a resolution of 16 bits and converts input signal to Integer data format.
Technical Specifications for 1769sc-IF4IH
| Input Current | 0-20 mA, 4-20 mA |
| Certicications | UL/cUL Listed ANSI ISA 12.12.01 (Class I, Div 2, Groups ABCD), CE |
| Update Times | 18 to 488 ms, all channels 6 seconds for HART |
| Accuracy | ±0.2% of range voltage ±0.35% of range current |
| Channel filter frequencies | 28.5 Hz, 50 Hz, 60 Hz, 300 Hz, and 360 Hz |
| Configurable Data Formats | Engineering units, Scaled-for-PID, Percent of full-scale, Raw/proportional data |
| HART Variables | PV, SV, TV, FV |
| Resolution | 16-bits |
| Input Voltage | 0-5 V, 1-5 V, 0-10 V, ±10 V |
| Manufacturer | Spectrum Controls |
| Part Number/Catalog No. | 1769sc-IF4IH |
| Product Type | Analog+ HART Input Module |
| Rockwell Compatible Series | CompactLogix / MicroLogix 1500 |
| Brand | Allen-Bradley |
| Inputs | 4 |
| Input Types | Analog plus HART |
| Data Formats | Integer |
The 1769SC-IF4IH is an compass partner module that is compatible for use with the CompactLogix and MicroLogix 1500 Programmable Automation Controllers (PAC). This module is manufactured by Spectrum Controls for the 1769 Compact I/O system. The 1769SC-IF4IH is an analog input module with Highway Addressable Remote Transducer (HART) capability. This module accepts 0-20 mA and 4-20 mA Current signals plus HART capability. It is also compatible with 0-5VDC, 1-5VDC, 0-10VDC and +/- 10VDC input voltages. This module has an analog input resolution of 16-Bits and support HART dynamic variables of PV, SV, TV and FV. It has Five (5) filter frequencies, selectable by the user, individually for each channel. Available channel frequencies are 28.5 Hz, 50 Hz, 60 Hz, 300 Hz, and 360 Hz. This module has an update time of 18 to 488 ms for all channels and Six (6) second update time for HART. The 1769SC-IF4IH has an internal analog to digital converter. Converted data is saved in Integer data format which can be further defined as engineering units, Scaled for PID, Percent of Full-scale and Raw / proportional data. This module is a single slot module that may be installed to any adjacent module of the CompactLogix chassis. It has compatible levers to allow connection to adjacent pins to establish bus connection. The 1769SC-IF4IH has a module accuracy of ±0.2% of range voltage and ±0.35% of range current. It is factory calibrated and carries certifications from UL/cUL Listed ANSI ISA 12.12.01 (Class I, Div 2, Groups ABCD), CE.
