1794-OB32P - Digital DC Output Module

Description

Description: The 1794-OB32P is an Allen-Bradley Flex I/O electronically protected discrete output module. This module comes with individual channel protection, having thirty-two (32) 24 Volt DC sourcing output channels. It is compatible for use with the 1794-TB32 and 1794-TB32S terminal base units. It has an output current rating of 14.0 Amperes per module, with 6 Amperes total for channels 0...15 and 8 Amperes total for channels 16-31.

Technical Specifications for 1794-OB32P

The Allen-Bradley 1794-OB32P is a FLEX I/O digital 24V DC module. It comes with 32 outputs that are electronically fused and grouped into 2 groups of 16 outputs, with each group having a separate voltage source. Each output is self-protected against temperature overloads and shocks. It also has 32 yellow status indicators and measures 1.8 x 3.7 x 2.1 inches. The 1794-OB32P can be installed using a DIN rail mount and is only compatible with the 1794-TB32 and 1794-TB32S terminal base units. The on-state output voltage of the 1794-OB32P module ranges from a minimum of 10V DC and a maximum of 31.2V DC and it also has a maximum on-state output voltage drop of 0.5V DC. Per channel, the module has a minimum on-state current output of 1 mA and a maximum on-state output of 500 mA per channel, or a total of 14 A per module. However, this module has a varying total number of amperes for the 2 output groups, as Channels 0-15 have a total of 6 A while Channels 16-31 has a total of 8 A. The module has a maximum output surge current of 2 A for 50 ms, which is repeatable every 2 s, as well as an off-state output leakage current of 0.5 mA. The 1794-OB32P’s external DC supply current range is 103-273 mA and its external DC supply voltage range is 10-31.2V DC, with the 5% AC ripple included. This module has a maximum output delay of 0.5 ms from OFF to ON state and 1 ms from ON to OFF state. It also has a continuous isolation voltage of 50V between the field side and the system. The 1794-OB32P has a maximum thermal dissipation of 18.1 BTU/hr at 31.2V DC and a maximum power dissipation of 5.3 W also at 31.2V DC.

The Allen-Bradley 1794-OB32P is a sourcing discrete output module. This module is part of the Flex I/O product family, featuring thirty-two (32) electronically protected output channels. Discrete output modules, including the 1794-OB32P, are used to implement the control output commands of Programmable Logic Controllers (PLC). Specifically, the 1794-OB32P is especially compatible for use with electronic and electrical components operating at 24 Volts DC voltage such as indicating devices like pilot lamps and revolving light; Sounding devices such as buzzer, horn and siren; Electrical loads such as relay coils, solenoid actuated devices, and similar components. The 1794-OB32P output module is used with terminal base units. Compatible terminal base units are 1794-TB32 and 1794-TB32S. This module has a maximum output current of 14.0 Amperes; maximum of 6 Amperes delivered by channels 0-15 and maximum of 8 Amperes provided by channels 16-31 while the minimum output current rating per channel is 1.0 milliampere. It has a minimum on-state voltage output of 10 Volts DC, a nominal on-state output voltage of 24 Volts DC, and a maximum on-state output voltage of 31.2 Volts DC. The module exhibits an output signal delay of 0.5 milliseconds for off-to-on transition and 1.0 millisecond for on-to-off transition. It has a current draw of 80 milliamperes @ 5 Volts DC, a maximum power dissipation of 5.3 Watts @ 31.2 Volts DC, and a maximum thermal dissipation of 18.1 British Thermal Units (BTU) per hour @ 31.2 Volts DC.
